Bartington 3-axis Miniature/Low Power (Mag648/612/639/690)

Bartington 3-Axis Fluxgate Sensors are compact, high performance fluxgate sensors with integral electronics that provide precision measurements of static and alternating magnetic fields in three axes. Mag-13 Fluxgate Sensors can be used for most applications where high precision magnetic field measurements are required. A very low noise option is now available!

Features

Mag612 (Miniature): Range ±90µT, Bandwidth DC-3kHz min, Noise 10-≤20pTrms/√Hz@1Hz, Dimensions 20x20x20mm | Mag619 (Low Profile): Range ±60/100µT, Bandwidth DC-3kHz min, Noise >10-≤50pTrms/√Hz@1Hz, Dimensions 25x20x11mm | Mag648/Mag649 (Low Power): Range ±60/100µT, Bandwidth Mag648>30Hz / Mag649>1kHz, Noise <10-50pTrms/√Hz@1Hz, Dimensions 30x32x70mm | Mag639 (Wide Bandwidth): Range ±100µT, Bandwidth 0-12kHz@50%FS, Noise <20pTrms/√Hz@1Hz, Dimensions 25.4x218mm | Mag690 (Lower Cost): Range ±100/1000µT, Output ±10V FS, Bandwidth DC->1kHz, Noise <25pTrms/√Hz@1Hz, Dimensions 122x32x32mm
